APT Mfg Solutions Mod-Weld Cobot MAC Bundle

Choice of: Miller Auto-Continuum 350 or Fronius TPSi-400

FANUC CRX-10iA/L or FANUC CRX-25iA Collaborative Robot with APT Clever Torch teach button software package ready to teach and weld Operator pushbutton panel integrated to robot controller. Cycle start, teach enable End user to install robot, controller, etc. to existing fixture table, base, or pedestal Base model is configured to weld steel (hard metal), soft metals require additional options Choose Your Power Supply Fronius

400i TPSi, air-cooled torch for welding steel. Comes with .035 wire feed rollers 3PH Power. Optional consumable or replacement parts up to 1/16

Miller

350C/D Auto-Continuum™ 3PH or Auto-Deltaweld™ 1PH, air-cooled torch for welding steel. Comes with .035 wire feed rollers. Optional consumable or replacement parts up to 1/16 Software Options

Fronius

PMC Fronius Pulse Multi-Control, regulated, low-spatter droplet detachment. At the same time, PMC generates a stable arc which results in perfect control of the weld pool. LSC Fronius Low Spatter Control, achieves high-quality weld seams with minimal spattering and increased deposition rate, as the LSC principle is based on the short circuit occurring at a low current level. This leads to soft reignition and a stable welding process. FANUC

TPW FANUC Thick Plate Weld Package is Touch Sensing & Through Arc Seam Track in one package. This robot/cobot software is available on both Fronius & Miller APT Features APT Clever Torch kit for CRX. Torch mounted integral buttons for aiding in programming of CRX robot. Clever torch has two buttons, one for selecting movement and one for teaching point. Operator panel with 15′ pigtail and integrated to robot I/O by APT. Button station will contain cycle start button and teach enable selector switch. Faunc Features

Fanuc CRX 10iA/L six axis collaborative robot with FANUC R30iB Mini Plus controller. 10kg (22 lbs.) maximum payload with 1,418mm (55.8 in) reach. The FANUC CRX cobot is safe, flexible, quick to implement and easy to program. The robot will stop upon contact with people. It is human friendly with a smooth and rounded design.
